The Transportation Safety Board of Canada (TSB), which is prevented statutorily from issuing judgements or finding blame, started an investigation into the accident under reference R13D0054, deploying a team of 20 experts to the site to gather evidence and interview officials and witnesses.
While the investigation was underway, the Transportation Safety Board asked Transport Canada to review the Canadian Rail Operating Rules and special instructions by railways that cover securing equipment.
They also advised that trains carrying dangerous goods should not be left unattended on a main track. On July 8, Transport Canada investigated a second MMA train reported by police as unattended since July 5 on the Vachon Station siding near Frontenac. That train had been parked on a slope with only five handbrakes set and did not comply with federal regulations.
At least nine brakes should have been used to secure the train on level track, with additional handbrakes applied when on an incline. A local resident had posted online video of an unattended locomotive with a cabin door ajar and an engine left running.
On July 19, Transportation Safety Board of Canada chief investigator Donald Ross said “Not enough brakes were applied to the train that derailed. A sufficient number of brakes needed to be applied and the quality of brakes needs to be examined.” TSB investigators looked into the air brake system which is normally charged to 90 PSI (621 kPa) and, when the engineer reduces the air pressure to 65 pounds per square inch (448 kPa), applies the brakes.
Investigators tried to determine how the air brakes were released by examining the theory that a relatively small change in air pressure could have produced a “pressure wave” to trigger a quick release of the brakes. However, Wally Kirkpatrick, manager of rules and operations at RTC Rail Solutions, said the air brakes could have leaked off over time once the engine was shut down.
Because crude oil generally does not readily ignite, TSB investigators looked into the composition of the train’s cargo. Theories under investigation were: The oil may have contained additives to speed up the transfer of the syrupy oil. This is common when shipping via pipelines but rare for shipping by rail. There may have been chemical contaminants in the tank cars from a previous shipment. However, the MMA had a detailed bill of lading from a U.S. oil services company stating there were no chemicals in the crude.
The oil may have been contaminated with chemicals used in the fracking process. Bakken oil can contain high levels of hydrogen sulphide gas; hydrogen sulphide is flammable, corrosive, poisonous, and explosive. Pipeline operators Tesoro and Enbridge no longer accept crude with more than five parts per million H2S, citing safety concerns. A local propane tank near the derailment might have exploded when struck by a rail car. High temperatures in Quebec at the time of the derailment may have made the oil cargo more flammable.
The TSB concluded that the severity of the fire was due largely to the large amount of oil rapidly released and the oil’s inherent physical properties; there was no evidence of contamination with fracking additives or hydrogen sulphide gas.
On July 19, 2013, the TSB issued an urgent safety advisory requesting that Transport Canada consider reviewing all railway operating procedures to ensure that trains carrying dangerous goods are not left unattended on the main track. Also on July 19, the TSB issued another urgent safety advisory requesting that Transport Canada review Rule 112 of the Canadian Rail Operating Rules (CROR) and all related railway special instructions to ensure that equipment and trains left unattended are properly secured in order to prevent unintended movements.
The TSB noted that most railway special instructions specify the minimum number of hand brakes needed in general operating conditions but not always for specific conditions. It is often left up to the operating employee to determine the number of hand brakes to apply. The employee must take into consideration the slope or grade of the track and the approximate tonnage of the equipment to be secured at a specific location.
The TSB also noted that the effectiveness of the hand brake system varied from car to car depending on the design, condition and maintenance, and also from one operator to another due to differences in physical capability and personal technique. The TSB also stated that it is inadequate for railway operators to depend on the push–pull test to verify whether the hand brakes can hold the cars. On August 1, the TSB said it has taken samples of the oil for analysis. Both Canadian and US investigators have found the Bakken crude was not identified correctly in shipping documents, and the incorrect classification led to its volatility being underestimated.
The following month, the TSB identified a defective piston in the head engine as the cause of the original fire in Nantes. Transport Canada issued notices of non-compliance after inspection of six track segments found fair to substandard rail conditions which legally must be fixed, including a concentration of defective ties on a section near a propane storage facility. On September 12, following a failed inspection, Transport Canada shut down one segment of the MMA line until hazards could be fixed. Subsequent inspections led to an October 11 embargo on the line between Lennoxville and Lac-Mégantic.
On August 19, 2014, the TSB issued its report documenting findings and recommendations.
Factors related to the locomotive (5017), the lead locomotive on the derailed train:
Mechanical problems not remedied:
An engineer reported trouble with the locomotive 5017’s engine on a separate trip two days before the crash in Lac-Mégantic. The locomotive remained in service despite that concern. Non-standard engine repair failure: A quick and cheap repair using inappropriate materials allowed oil to accumulate in the turbocharger and exhaust manifold, resulting in a fire. Locomotive engine fire: In order to put out the fire, the Nantes fire department shut down the locomotive thus inadvertently disabling the air brakes.
Safety device not wired to initiate braking: The “reset safety control” system was not wired to set the entire train’s brakes in the event of an engine failure. Factor related to the tank cars: Breached tank cars and highly volatile crude oil: The tank cars were prone to puncture and the Bakken oil was highly volatile.
Factors related to Transport Canada’s role in providing oversight of railway operations:
Inadequate oversight of operational changes: Transport Canada did not provide adequate regulatory oversight to ensure the associated risks were addressed when the MMA made significant operational changes. Limited follow-up on safety deficiencies:
Transport Canada did not follow up to ensure that recurring safety deficiencies were dealt with. Inefficient program to audit safety management systems (SMS): Audits were limited in frequency and scope and had no follow-up procedure. Factor related to the derailment: Excessive train speed for track: At the point of derailment, the train was travelling at 105 km/h, more than triple the typical speed for that location.
Factors related to train securement: Independent air brakes leaked off: With all the locomotives shut down, the air compressor no longer supplied air to the air brake system. As air leaked from the brake system, the main air reservoirs were slowly depleted, gradually reducing the effectiveness of the locomotive air brakes.
Improper handbrake test: The engineer erroneously did the brake test with the locomotive air brakes left on. This gave the false impression that the hand brakes alone would hold the train. Insufficient hand brakes: The engineer set 7 hand brakes. The TSB said that a minimum of 17 were technically required and perhaps as many as 26.
Factors related to MMA practices: Train left unattended on hill: The train was parked unattended on the main line, on a descending grade, and the securement of the train was reliant on a locomotive that was in deteriorating operating condition. No additional safety defenses: No additional physical safety defenses (such as a derail) were in place to prevent the uncontrolled movement of the train. Ineffective training and oversight on train securement: The MMA did not provide effective training or oversight to ensure that crews understood and complied with rules governing train securement. Weak safety culture: The MMA was reactive rather than proactive when it came to safety.
The MMA had weak safety training. There were also significant gaps between the company’s operating instructions and how work was done day to day.
Safety management system (SMS) not fully implemented: Although MMA had developed a safety management system in 2002, the company did not begin to implement it until 2010. By 2013, the SMS was still not functioning effectively.
Not effectively managing risks: When making significant operational changes, the MMA did not thoroughly identify and manage the risks to ensure safe operations. Single person train operation was initially investigated as a 19th factor in the derailment, but the investigation was not able to conclude whether having another crew member would have prevented the accident. It was thus omitted from the final report. A second operator could have provided a second opinion about the thick smoke from the defective engine or verified the number of brakes to be set to hold the train on an incline. The TSB report also contains 16 findings as to risk even though these safety risks did not lead directly to the accident.
Some of the risks that the TSB recommends being addressed are: The continuing risk of leaving trains unattended. The risk of implementing single-person train operations. The risk of not systematically testing petroleum crude oil. The risk of not planning and analyzing routes on which dangerous goods are carried. The risk of not having emergency response assistance plans in place. The risk of Transport Canada not ensuring that safety management systems work effectively.
